Silver Plated Copper high temperature PFA Insulated Heat Resistant Electric Wire

PFA Insulation wire can be rated up to 250°C, thus making it an excellent choice for high temperature applications. Along with excellent temperature ratings. PFA has outstanding resistance to chemicals at high temperatures as compared to FEP insulation wire, and also remains flexible at low temperatures.

Applications:

Connection lines for mechanical equipment, industrial machines, electronic products, automation equipment, household appliances,medical equipment, car navigation systems, automotive control systems, etc.

Using Condition

1. Rated voltage: AC600V and Below
2. Working temperature: -65 Degree ~ +250 Degree

3. Insulation resistance is not less than 1x103MΩ
4. Wire relative humidity: 95%±3.
5. Test Voltage: (Under AC 50Hz )2000V/5min

Specification:

Insulation: PFA insulated

Conductor: Silver plated copper

Core Number: Single Core or Multi Cores

Available Colors: Red, Black, White, Yellow, Brown, Blue, Orange and etc...

Sanco cable is a leading manufacturer and supplier of custom wires and custom cables which mainly engaged in production of high temperature wire,high temperature wire,aerospace lead wire,industrial robot cable, electromagnetic shielding cable, watertight cable, crane cable, drag chain cable, charging pile cable.These wires and cables are widely used in national defense, aerospace, robot, oil field, wind power, rail transportation, high-speed rail locomotives, new energy vehicles, port machinery, communications, electronics and other fields.
Our factory has a technical exquisite experienced team, the perfect quality control system ,to provide the high quality suitable product for the customer all over the world ,including USA,Mexico,France,Croatia,Czech republic,Pakistan and some other countries.
After 18 years’ development, We have achieved great progress, Our products have been used in the Project of National Rocket and China Manned Space Engineering Program.And passed the armed equipment quality management system certification. Our R&D department provide the strong technical support and enable us to receive some O E M, O D M projects.
By our excelsior spirit, professional technology, excellent quality, perfect after-sales service, we sincerely look forward to cooperating with you!
